Galvanised Serrated Steel Grating for Platform Steel Floor Projects
High-quality galvanised serrated steel grating designed for industrial platform and steel floor applications. Our grating provides superior slip resistance, durability, and load-bearing capacity.
Bearing Bar Specifications
Available in various configurations to meet your project requirements:
- Plain & Serrated Type: 25 x 3 mm to 100 x 8 mm
- I-Section Type: 25 x 5 x 3, 32 x 5 x 3, 38 x 5 x 3, 40 x 5 x 3, 50 x 5 x 3, 50 x 7 x 4, 55 x 7 x 4, 60 x 7 x 4, 65 x 7 x 4, 70 x 7 x 4, 75 x 7 x 4, and more
Bearing Bar Pitch Options
Center-to-center spacing available in: 12.5, 25, 30, 30.16, 32.5, 34, 40, 41.25, 45, 50, 60, 60.32, 80, 100 mm
Recommended: 30mm, 40mm, 60mm
American Standards: 1" x 3/16", 1 1/4" x 3/16", 1-1/2" x 3/16", 1" x 1/4", 1-1/4" x 1/4", 1 1/2" x 1/4" (19-w-4) and more
Material & Surface Treatment
- Materials: Mild Steel (Low Carbon Steel) or Stainless Steel
- Surface Treatments: Untreated, Painting, or Hot Dip Galvanizing
International Standards Compliance
- China: YB/T4001-1998
- USA: ANSI/NAAMM (MBG531-88)
- UK: BS4592-1987
- Australia: AS1657-1985
- Japan: JJS
Detailed Product Specifications
| Component |
Specifications |
| Bearing Bar |
25x3, 25x4, 25x4.5, 25x5, 30x3, 30x4, 30x4.5, 30x5, 32x5, 40x5, 50x5, 65x5, 75x6, 75x10, 100x10mm and more
I bar: 25x5x3, 30x5x3, 32x5x3, 40x5x3 etc.
US standard: 1"x3/16", 1 1/4"x3/16", 1 1/2"x3/16", 1"x1/4", 1 1/4"x1/4", 1 1/2"x1/4", 1"x1/8", 1 1/4"x1/8", 1 1/2"x1/8" etc.
|
| Bearing Bar Pitch |
12.5, 15, 20, 25, 30, 32, 35, 38, 40, 60, 80mm etc.
US standard: 19-w-4, 15-w-4, 11-w-4, 19-w-2, 15-w-2 etc.
Note: 19-W-4 is most popular (19/16 inch x 4 inch opening = 30x100mm opening)
|
| Twisted Cross Bar Pitch |
50, 60, 76, 100, 120mm etc.
US standard: 2" & 4" etc.
|
| Surface Treatment |
Black, self colour, hot dip galvanized, painted, spray coating |
| Grating Style |
Plain / Smooth, Serrated / teeth, I bar, serrated I bar |
